105W 19.4V Flexible Solar Power Panel, 360 Degree Bendable Solar Module for Curved Surfaces

Product Categories
KUOMAN INDUSTRY LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

105W 19.4V Flexible Solar Power Panel, 360 Degree Bendable Solar Module for Curved Surfaces

  • 1
  • 2

Model Number : KMRX200W

Current At Pmax : 8.34A(IMP)

Place of Origin : China

Panel Efficiency : >=23%

Price : USD1-100/pcs

Panel Dimensions : 115*98.5CM

Design Voltage : 19.2V

Delivery Time : general two weeks, more quantity based on exact quantity

Open-circuit Voltage : 21.9V

Product Architecture : 7-layer process

Supply Ability : 10000pcs/month

Peak Voltage : 18V

Packaging Details : standard international carton packing

Short-circuit Current : 5.75A

Solar Panel Efficiency : 24.20%

MOQ : 1set

Max Power : 100W

Maximum Power Current : 5.5A

Brand Name : KUOMAN

Material : poly silicon

Contact Now

105W 19.4V Flexible Solar Power Panel, 360 Degree Bendable Solar Module for Curved Surfaces
Product Overview

Our 100W high‑efficiency flexible solar panel is engineered for off‑grid mobile power solutions. Built with premium carbon‑fiber & FFC materials, this lightweight bendable solar module delivers stable solar power without cracking under curved installation. Weighing only 2kg and equipped with an IP68 waterproof junction box & standard MC4 connector, it provides long‑lasting, reliable renewable energy for your outdoor adventures, mobile living and off‑grid power projects.

105W 19.4V Flexible Solar Power Panel, 360 Degree Bendable Solar Module for Curved Surfaces

Solar Panel Specifications
Power Open-circuit Voltage (Voc/V) Short-circuit Current (Isc/A) Design Voltage (Vmp/V) Maximum Power Current (Imp/A) Solar Panel Efficiency(%) Product Architecture SIZE
100W 21.9V 5.75A 19.2V 5.5A 24.20% 7-layer process 918*580*2.5mm
120W 22.6V 6.93A 19.2V 6.63A

1084*580*2.5mm
150W 21.21V 9.24A 18V 8.84A

1020*764*2.5mm
180W 21.21V 11.1A 18V 10.61A

1203*764*2.5mm
200W 23.1V 11.09A 19.8V 10.6A

1316*764*2.5mm
250W 22.5V 13.89A 19.2V 13.28A

1279*948*2.5mm
300W 44.9V 8.64A 38.5V 8.26A
9-layer process 1618*948*2.5mm
350W 44.54V 9.87A 37.9V 9.44A

1799*948*2.5mm
400W 44.54V 11.62A 37.8V 11.11A

1771*1132*2.5mm
450W 42.42V 13.84A 36.12V 13.23A

1977*1132*2.5mm
500W 42.42V 15.26A 36.12V 14.59A

2164*1132*2.5mm
105W 19.4V Flexible Solar Power Panel, 360 Degree Bendable Solar Module for Curved Surfaces
200W Flexible Solar Panel Features
  • Rated Max Power: 105W, ±5% power tolerance
  • Optimal Working Voltage:19.4V, Open‑circuit Voltage:24.4V
  • High solar cell conversion efficiency: Over 22%
  • 360° bendable carbon‑fiber construction, anti‑micro‑crack performance
  • Light‑weight 2kg PET black surface, ultra‑thin 14.5mm profile
  • IP68 fully waterproof junction box for all‑weather outdoor use
  • Standard MC4 connector for quick, secure wiring
  • Corrosion‑resistant, salt‑water safe for marine environments
  • No professional installation required, easy DIY mounting
Product Specifications
  • Rated Max Power: 105W, ±5% power tolerance
  • Optimal Working Voltage:19.4V, Open‑circuit Voltage:24.4V
  • High solar cell conversion efficiency: Over 22%
  • 360° bendable carbon‑fiber construction, anti‑micro‑crack performance
  • Light‑weight 2kg PET black surface, ultra‑thin 14.5mm profile
  • IP68 fully waterproof junction box for all‑weather outdoor use
  • Standard MC4 connector for quick, secure wiring
  • Corrosion‑resistant, salt‑water safe for marine environments
  • No professional installation required, easy DIY mounting

105W 19.4V Flexible Solar Power Panel, 360 Degree Bendable Solar Module for Curved Surfaces

Application Scenarios
