170W 66‑Cell 182mm Monocrystalline Solar Panel, Easy‑Mount Frame For Rooftop Shed Installation

  • 1
  • 2

Model Number : JST-EWMH-(160-170)W

Dimensions : 1105×765×30mm

Supply Ability : 2000 pcs/month

Module Efficiency : 18.93%-20.11%

Power Tolerance : 0~+4.99W

Price : based on quantity

Open Circuit Voltage : 23.18V-23.34V

Max Series Fuse : 10A

Packaging Details : 1105×765×30mm

Current at Pmax : 8.00A-8.39A

Maximum System Voltage : 700Vdc

Maximum Power : 160W-170W

Voltage at Pmax : 19.99V-20.26V

Mechanical Load : Front 5400Pa / Rear 2400Pa

Place of Origin : China

MOQ : 1

Short-Circuit Current : 8.43A-8.82A

Brand Name : KUOMAN

Weight : 9.11kg

Contact Now

170W 66‑Cell 182mm Monocrystalline Solar Panel, Easy‑Mount Frame For Rooftop Shed Installation
170W 66‑Cell 182mm Monocrystalline Solar Panel, Easy‑Mount Frame For Rooftop Shed Installation
Product Highlights

Our (160‑170)W monocrystalline PV panel adopts premium 182mm 66‑cell solar cells, delivering stable rated power from 160W up to 170W with high‑efficiency up to 20.11%. Manufactured with durable 3.2‑mm tempered glass and sturdy aluminum frame, this compact‑size solar module works reliably under harsh outdoor conditions. It is a versatile off‑grid power solution perfect for residential, camping, RV and remote‑area power supply.

Key Specifications
Electrical Characteristics 160W 170W Mechanical Specifications
Maximum Power (Pmax) 160W 170W External Dimensions: 1105*765*30mm
Open Circuit Voltage (Voc) 23.18V 23.34V Weight: 9.11kg
Short-Circuit Current (Isc) 8.43A 8.82A Solar Cells: Monocrystalline 182*60.66mm (4*17pcs)
Voltage at Pmax (Vmp) 19.99V 20.26V Front Glass: 3.2mm Tempered Glass
Current at Pmax (Imp) 8.00A 8.39A Frame: Anodized Aluminum
Module Efficiency (ηm) 18.93% 20.11% Junction Box: IP67
Power Tolerance 0~+4.99W 0~+4.99W Output Cables: 90cm (customizable)
Maximum System Voltage 700Vdc (IEC/UL) 700Vdc (IEC/UL) Connector: MC4 Compatible
Max Series Fuse Rating 10A 10A Mechanical Load: Front 5400Pa / Rear 2400Pa
Key Advantages
  • Unmatched Efficiency: 20.11% module efficiency (170W model) generates more power per square meter than competing 160-170W panels.
  • 700V System Ready: Supports large-scale series connections for utility-grade or industrial off-grid systems.
  • Built to Endure: IP67 junction box, 3.2mm tempered glass, and 5400Pa wind/snow load resistance ensure decades of reliable performance.
  • Scalable Design: Customizable cable lengths and MC4 compatibility simplify integration into complex PV arrays.
Frequently Asked Questions
Q: Can this panel charge a 24V battery?
A: Yes! The Vmp (19.99-20.26V) is ideal for 24V battery systems (with a compatible charge controller).
Q: How many panels fit on one pallet?
A: 36 panels per pallet (dimensions: 1155*1130*885mm; weight: 325kg).
Q: Is it suitable for coastal areas?
A: Absolutely. The IP67 junction box and corrosion-resistant aluminum frame withstand salt, moisture, and extreme weather.
Application Scenarios
170W 66‑Cell 182mm Monocrystalline Solar Panel, Easy‑Mount Frame For Rooftop Shed Installation
  • Large Off-Grid Homes: Primary power for remote cabins, farms, or eco-resorts.
  • Commercial Rooftops: Small businesses, warehouses, or agricultural facilities seeking energy independence.
  • Telecom & Utilities: Powers remote cell towers, weather stations, or grid-tied backup systems.
  • Mobile Applications: Heavy-duty RV solar systems, large boats, or mobile command centers.
Packing Configuration
  • Module Dimensions: 1105*765*30mm
  • Pallet Dimensions: 1155*1130*885mm
  • Pallet Weight: 325kg
  • Pieces per Pallet: 36
